China One Stop custom Polyimide boards FPC flexible printed circuit board pcb manufacturer POE Supplier

China One Stop custom Polyimide boards FPC flexible printed circuit board pcb manufacturer POE Supplier

Get a Price/Quote

Product Details:

Silkscreen White/Black/Yellow
Min. Line Width 0.05 mm
Hole Size Min 0.15 mm
Board Type Rigid-Flex / Flex / Single-sided / Double-sided
Test 100% E-test and AOI
Voltage Endurance >500V
Insulation Resistance >10^12
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

China One Stop custom Polyimide boards FPC flexible printed circuit board pcb manufacturer POE Supplier Price And Quantity

Minimum Order Quantity 1 Piece

China One Stop custom Polyimide boards FPC flexible printed circuit board pcb manufacturer POE Supplier Product Specifications

Min. Line Spacing 0.05 mm
Soldermask Yellow / Transparent / Customizable
Flame Resistance Level UL 94V-0
Base Material Polyimide PI
Panel Size Custom up to 600mm x 1200mm
Electrical Components Dependent on customer design
Copper Thickness 0.3-2.0 oz
Number Of Layers 1-8 Layers
Board Thickness 0.1 mm-0.3 mm
Hole Size Min 0.15 mm
Sensor Switch Customizable options
Color Yellow Polyimide
Silkscreen White/Black/Yellow
Min. Line Width 0.05 mm
Impedance Controlled Impedance available
Surface Finish OSP, ENIG, Gold plating, Silver, HASL, Immersion Tin
Insulation Resistance >10^12
Product Type FPC Flexible Printed Circuit Board
Voltage Endurance >500V
Test 100% E-test and AOI
Board Type Rigid-Flex / Flex / Single-sided / Double-sided

Process Standard IPC Class 2 / Class 3 compliant
Storage Life 12 Months (recommended conditions)
Thermal Resistance Excellent thermal cycling reliability
Copper Foil Type Rolled Annealed (RA) or Electro Deposited (ED)
Application Consumer electronics, Automotive, Medical, Industrial control, Aerospace
Packing Vacuum package with anti-static bag
Maximum Working Temperature up to 260C
Peel Strength 0.8 N/mm
Monthly Output 50,000 sq.m
OEM/ODM Service Available
Lead Time Prototype in 48 hours
Connector Type Custom design/fitted as per requirements
Flexibility High bending and flex durability
RoHS Compliance Yes

Product Description

Discover the redoubtable POE Supplier-China's top-rated, one stop custom Polyimide boards FPC flexible PCB manufacturer. Renowned for reduced lead times, POE offers formidable flexibility and high durability for complex OEM and ODM applications. Each board adheres to strict IPC Class 2/3 process standards, ensuring reliable performance in demanding environments. Benefit from robust thermal resistance (up to 260C), customizable sizes, and compliance with RoHS and UL 94V-0 standards. Find solutions ideal for automotive, aerospace, medical, consumer electronics, and industrial control. Enjoy vacuum-packed, anti-static protection and rapid prototype handover within 48 hours.

Specific Usage and Diverse Applications

China One Stop custom Polyimide boards FPC flexible printed circuit boards are meticulously engineered for high-flex, high-reliability applications. These boards excel in advanced consumer electronics, medical devices, automotive sensors, and aerospace technology. Their formidable thermal cycling endurance and custom connector compatibility make them suitable for industrial control, instrumentation, and communication equipment. Explore tailored options for sensor switches or specialized electrical components, satisfying straightforward to highly intricate project demands across varied industries.

Swift Handover and Shipping Advantages

Experience exceptionally reduced shipment times with POE's prototype handover within a formidable 48 hours. Orders are processed via efficient FOB port operations, accommodating global clients as well as the main domestic market in India. Product shipment and delivery are securely managed in vacuum-sealed anti-static packaging, ensuring peak quality on charge-free arrival for qualifying orders. Clients benefit from transparent logistics, quick turnaround, and robust after-sales support, reinforcing POE's reputation as a top exporter and manufacturer.

FAQ's of China One Stop custom Polyimide boards FPC flexible printed circuit board pcb manufacturer POE Supplier:

Q: How does POE Supplier ensure quick prototype handover for custom FPC boards?

A: POE Supplier delivers prototypes in just 48 hours through advanced manufacturing processes and streamlined order management, ensuring your custom FPC boards reach you swiftly.

Q: What are the key benefits of using Polyimide boards from this manufacturer?

A: Polyimide boards offer notable flexibility, formidable thermal resistance, and outstanding durability. They are RoHS-compliant, boast high peel strength and flame resistance, and suit applications requiring reliability in challenging environments.

Q: Where can these flexible PCBs be utilized?

A: These PCBs are designed for a broad spectrum of applications, including consumer electronics, automotive modules, medical devices, industrial control systems, and aerospace equipment.

Q: What is the typical process for customizing a printed circuit board with POE?

A: Simply provide your design specifications and required fittings; POE's design and engineering team will collaborate with you to create tailored boards, ensuring IPC compliance and meeting all technical needs.

Q: When should original equipment and design manufacturers consider using these flexible PCBs?

A: Manufacturers should choose these flexible PCBs for projects demanding high bend cycles, excellent thermal reliability, and space-saving configurations, particularly in industries with stringent technical standards.

Q: How is the shipment of the Polyimide boards managed to ensure safety?

A: All Polyimide boards are vacuum-sealed and packaged in anti-static bags to prevent moisture ingress and static damage during transport, maintaining product integrity until delivery.
