Universal Double Sided Breadboard PCBA Circuit Protoboard 2x8 3x7 4x6 5x7 7x9CM Stripboard Prototyping Board DIY Electronic Kit

Universal Double Sided Breadboard PCBA Circuit Protoboard 2x8 3x7 4x6 5x7 7x9CM Stripboard Prototyping Board DIY Electronic Kit

Get a Price/Quote

Product Details:

Impedance Not controlled
Voltage Endurance 250V AC
Test Visual inspection
Flame Resistance Level UL94V-0
Board Type Stripboard/Protoboard
Min. Line Spacing 0.3mm
Soldermask Green
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Universal Double Sided Breadboard PCBA Circuit Protoboard 2x8 3x7 4x6 5x7 7x9CM Stripboard Prototyping Board DIY Electronic Kit Price And Quantity

Price Or Price Range INR
Minimum Order Quantity 1

Operating Temperature Range -20C to +120C
Application DIY Electronics, Project Prototyping, Experimentation, Educational Kits
Drill Method Precision punched
Mounting Type Through Hole
Grid Pitch 2.54mm (standard spacing)
Pad Material Tinned Copper
Package Content 1 x Protoboard
Weight (per board) ~7g - 22g (depending on size)
Pattern Standard grid layout
RoHS Compliance Yes

Universal Double Sided Breadboard PCBA Circuit Protoboard 2x8 3x7 4x6 5x7 7x9CM Stripboard Prototyping Board DIY Electronic Kit Product Specifications

Base Material FR-4 Glass Epoxy
Flame Resistance Level UL94V-0
Test Visual inspection
Board Thickness 1.6mm
Sensor Switch No
Hole Size 1.0mm (approx.)
Min. Line Width 0.3mm
Electrical Components Not included (bare protoboard only)
Color Green
Insulation Resistance >10^6 M
Silkscreen White
Min. Line Spacing 0.3mm
Panel Size 2x8cm, 3x7cm, 4x6cm, 5x7cm, 7x9cm (varies by model)
Board Type Stripboard/Protoboard
Number Of Layers Double sided (2 Layers)
Surface Finish HASL (Hot Air Solder Leveling)
Product Type Universal Double Sided Breadboard PCBA Circuit Protoboard
Soldermask Green
Impedance Not controlled
Voltage Endurance 250V AC
Copper Thickness 1oz (35m)

Operating Temperature Range -20C to +120C
Application DIY Electronics, Project Prototyping, Experimentation, Educational Kits
Drill Method Precision punched
Mounting Type Through Hole
Grid Pitch 2.54mm (standard spacing)
Pad Material Tinned Copper
Package Content 1 x Protoboard
Weight (per board) ~7g - 22g (depending on size)
Pattern Standard grid layout
RoHS Compliance Yes

Product Description

Try Now the Universal Double Sided Breadboard PCBA Circuit Protoboard-an unmatchable platform for DIY electronics. Boasting dominant features like tinned copper pads and a laureate-quality FR-4 glass epoxy base, this protoboard guarantees durability and optimal conductivity. Available in versatile sizes (2x8, 3x7, 4x6, 5x7, 7x9CM), the through-hole mounting and precision punched drills offer superior prototyping flexibility. At a bargain discount, this RoHS-compliant stripboard makes experimentation, educational projects, and device prototyping seamless. Don't miss this premium deal-order now!

Feature-Packed Protoboard for Every Application

Engineered with standard 2.54mm grid, double-layered tinned copper pads, and FR-4 glass epoxy, this laureate stripboard ensures mechanical strength and lasting performance. Its through-hole design and precision punching allow seamless soldering for complex projects. Widely used in DIY electronics, prototyping, experimentation, and educational kits, this protoboard is dominant for both hobbyists and professionals. Operating efficiently from -20C to +120C, it supports reliable circuit assembly. The surface finish is HASL for consistent soldering, with a flame resistance level of UL94V-0.

Premium Export Quality & Efficient Dispatching

This premium Universal Double Sided Breadboard PCBA is widely dispatched across major export markets-including North America, Europe, and Asia-as well as all leading domestic markets in India. Our efficient logistics network assures swift and secure delivery. Samples are available upon request to facilitate testing before bulk orders. Trusted by professionals and educators alike, our supplier status ensures customers always receive high-quality, reliable prototyping boards, backed by responsive logistics and prompt support for all your electronics requirements.

FAQ's of Universal Double Sided Breadboard PCBA Circuit Protoboard 2x8 3x7 4x6 5x7 7x9CM Stripboard Prototyping Board DIY Electronic Kit:

Q: How is the Universal Double Sided Breadboard PCBA Circuit Protoboard used?

A: This protoboard is ideal for assembling and testing electronic circuits. Simply insert components into the board's holes and solder them to the tinned copper pads, following the standard 2.54mm grid for organized layouts.

Q: What makes this protoboard unmatchable compared to others?

A: The board features double-sided tinned copper pads, high-quality FR-4 glass epoxy material, and precision-drilled holes, ensuring dominant durability, laureate conductivity, and ease of use across a wide temperature range.

Q: Where can I order and receive this product?

A: You can order directly through our export, manufacturer, and supplier channels. We dispatch to major markets internationally and throughout India, supported by robust logistics for timely and secure delivery.

Q: Is a sample available before bulk purchasing?

A: Yes, samples of the Universal Double Sided Breadboard PCBA Circuit Protoboard are available. You can request a sample to evaluate the product before placing a larger order.

Q: What are the main benefits of using this protoboard for educational and project prototyping?

A: Users benefit from its standard grid spacing, reliable tinned copper pads, and flame-resistant FR-4 glass epoxy, making it perfect for hands-on learning, project experimentation, and reliable circuit prototyping.

Q: When can I expect dispatch after placing an order?

A: Upon order confirmation, products are promptly dispatched using premium logistics channels, ensuring quick and safe delivery to domestic and international destinations.
