Turnkey FR1 94V0 Custom OEM Electrical Circuit Board Custom PCBA (Printed Circuit Board)

Get a Price/Quote

Product Details:

Insulation Resistance >10^12
Board Type Rigid
Silkscreen White
Impedance Customized
Flame Resistance Level 94V-0
Test AOI, Functional Test
Voltage Endurance 220-440 Volt (V)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Turnkey FR1 94V0 Custom OEM Electrical Circuit Board Custom PCBA (Printed Circuit Board) Price And Quantity

Minimum Order Quantity 100 Unit

Assembly Type SMT/DIP/Mixed
Storage Temperature -20°C to +60°C
Design Support Yes
Mounting Type Through Hole, Surface Mount
Packing Type ESD Safe Packaging
Maximum Panel Size 18" x 24"
Application Consumer Electronics, Industrial Controls, LED Lighting, Power Supplies
OEM/ODM Service Available
Operating Temperature -40°C to +85°C

Turnkey FR1 94V0 Custom OEM Electrical Circuit Board Custom PCBA (Printed Circuit Board) Product Specifications

Soldermask Green
Min. Line Width 0.15 mm
Sensor Switch Optional
Board Thickness Different available Millimeter (mm)
Voltage Endurance 220-440 Volt (V)
Base Material FR1
Insulation Resistance >10^12
Panel Size Customizable
Test AOI, Functional Test
Warranty Yes
Impedance Customized
Product Type Electrical Circuit Board
Surface Finish HASL/OSP/ENIG
Flame Resistance Level 94V-0
Hole Size 0.3 mm min.
Min. Line Spacing 0.15 mm
Number Of Layers Single/Double
Board Type Rigid
Copper Thickness 35um
Silkscreen White
Color Green
Electrical Components As per BOM (Bill of Materials)

Assembly Type SMT/DIP/Mixed
Storage Temperature -20°C to +60°C
Design Support Yes
Mounting Type Through Hole, Surface Mount
Packing Type ESD Safe Packaging
Maximum Panel Size 18" x 24"
Application Consumer Electronics, Industrial Controls, LED Lighting, Power Supplies
OEM/ODM Service Available
Operating Temperature -40°C to +85°C

Turnkey FR1 94V0 Custom OEM Electrical Circuit Board Custom PCBA (Printed Circuit Board) Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 5000 Unit Per Month
Delivery Time 7 Days
Main Export Market(s) Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Product Description

Grab this must-have Turnkey FR1 94V0 Custom OEM Electrical Circuit Board Custom PCBA, a top-rated choice by industry leaders for matchless electronic applications. With superlative design support, it accommodates a variety of assembly types including SMT, DIP, and mixed. Manufactured in Vietnam, this impeccable solution ensures reliability for consumer electronics, industrial controls, and LED lighting. The board boasts customizable panel sizes, superior voltage endurance up to 440V, and exceptional insulation resistance (>10^12 ). Select from various finishes and thicknesses, and enjoy ESD safe packaging-all backed by warranty for absolute peace of mind.

Versatile Application and Outstanding Features

The Turnkey FR1 94V0 Custom PCBA excels in demanding environments such as consumer electronics, power supplies, and industrial controls. Its robust surface supports through-hole and surface mount applications while maintaining rigidity and flame resistance. Unique features include optional sensor switches, white silkscreen, multi-layer adaptability, and advanced AOI and functional tests. This board's green soldermask and matchless insulation resistance make it a must-have for reliable electronic integration.

Sample Availability and Reliable Logistics

Experience seamless dispatching with sample offers for the Turnkey FR1 94V0 Custom PCBA. FOB ports are available to provide flexible shipping choices, ensuring prompt delivery to your location. Our logistics system maximizes efficiency-from sample dispatch to bulk order shipment. The typical delivery time varies based on volume and customization, but expedited processing is always prioritized. Count on our commitment to superlative service standards and flawless order fulfillment.

FAQ's of Turnkey FR1 94V0 Custom OEM Electrical Circuit Board Custom PCBA (Printed Circuit Board):

Q: How can I customize the FR1 94V0 Circuit Board for my application?

A: You may specify panel size, electrical components by Bill of Materials (BOM), and select the number of layers, surface finish, and mounting type as per your project needs when placing your order.

Q: What is the process for ordering samples of the Custom OEM PCBA?

A: Sample requests are accommodated via our inquiry process. Once details are provided, we prepare and dispatch samples from our FOB port facilities, allowing you to inspect quality before confirming full orders.

Q: Where can the Turnkey FR1 94V0 PCBA be applied?

A: This circuit board is ideal for use in consumer electronics, LED lighting systems, industrial controls, and power supplies due to its exceptional durability and adaptability.

Q: When should AOI and functional tests be performed on the PCBA?

A: Automated Optical Inspection (AOI) and functional tests are conducted during the manufacturing process to ensure defect-free assembly and impeccable operational reliability before shipping.

Q: What benefits does the flame resistance and insulation offer?

A: With a flame resistance level of 94V-0 and insulation resistance greater than 10^12 , the board ensures safety, longevity, and stable performance even in demanding industrial settings.

Q: How is the product packed for safe delivery?

A: We utilize ESD safe packaging for all shipments, providing matchless protection against static electricity and physical damage during transit and storage.
