Product Details:

Board Type Rigid, Flexible, Rigid-Flex
Min. Line Width 0.075mm
Min. Line Spacing 0.075mm
Impedance Controlled Impedance Available
Flame Resistance Level UL94 V-0
Test Flying Probe, AOI, E-test
Voltage Endurance 2kV - 3kV
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Pcb rapid prototype services gerber file schematic electronic circuit board pcb pcba design and software development Supplier Price And Quantity

Minimum Order Quantity 1 Piece

Lead Time Prototype 2-5 Days, Batch 7-15 Days
File Format Supported Gerber, ODB++, Altium, Eagle, OrCAD
Operating Temperature -40C to +85C (Standard), Up to +150C for Special Material
Component Sourcing Full TurnKey, Partial TurnKey, Consigned
Design Service Schematic Design, PCB Layout, Firmware/Software Development
Packing Vacuum Packing, ESD Anti-static Bag
Max PCB Size 600mm x 1200mm
PCB Assembly Capabilities SMT, THT, Mixed Assembly, BGA, QFN, Fine Pitch Components
Application Fields Consumer Electronics, Automotive, Medical, Industrial Control, IoT, Communication

Pcb rapid prototype services gerber file schematic electronic circuit board pcb pcba design and software development Supplier Product Specifications

Silkscreen White, Yellow, Black, Custom
Insulation Resistance >10^12 Ohm
Soldermask Green, Blue, Black, Red, Yellow, White, Custom
Sensor Switch Optional / As per design
Hole Size Min 0.2mm
Color Green, Blue, Black, Custom
Number Of Layers 1-24 Layers
Base Material FR-4, Rogers, CEM-1, CEM-3, Aluminum
Panel Size Customizable
Electrical Components As per BOM (Bill of Materials)
Voltage Endurance 2kV - 3kV
Board Thickness 0.6mm - 2.0mm
Test Flying Probe, AOI, E-test
Flame Resistance Level UL94 V-0
Impedance Controlled Impedance Available
Copper Thickness 1oz - 3oz
Surface Finish HASL, ENIG, OSP, Immersion Silver, Immersion Tin
Product Type PCB Rapid Prototype Services
Board Type Rigid, Flexible, Rigid-Flex
Min. Line Width 0.075mm
Min. Line Spacing 0.075mm

Lead Time Prototype 2-5 Days, Batch 7-15 Days
File Format Supported Gerber, ODB++, Altium, Eagle, OrCAD
Operating Temperature -40C to +85C (Standard), Up to +150C for Special Material
Component Sourcing Full TurnKey, Partial TurnKey, Consigned
Design Service Schematic Design, PCB Layout, Firmware/Software Development
Packing Vacuum Packing, ESD Anti-static Bag
Max PCB Size 600mm x 1200mm
PCB Assembly Capabilities SMT, THT, Mixed Assembly, BGA, QFN, Fine Pitch Components
Application Fields Consumer Electronics, Automotive, Medical, Industrial Control, IoT, Communication

Product Description

Explore our new release in PCB rapid prototype services-crafted for those seeking the latest and rare electronic solutions. As a superior supplier of Gerber file schematic design, electronic circuit boards, PCB and PCBA, we deliver noteworthy capabilities, including SMT, THT, BGA, and fine pitch assembly. Experience gorgeous board finishes and unmatched flexibility-from 1-24 layers and custom panel and color options. Serving consumer electronics, medical, automotive, and IoT sectors, we offer fast 2-5 day prototyping, comprehensive software development, and robust application support, all manufactured in India to exacting standards.

Competitive Advantages and Application Fields

Benefit from our competitive advantage-rapid prototyping and versatile production for consumer electronics, automotive, medical, industrial control, and IoT applications. Our rare ability to customize dimensions, layers, finishes, and software support means you get a tailored solution every time. From small batches to mass production, each board meets stringent performance, reliability, and durability requirements, making our service the first choice for both everyday and noteworthy engineering projects.

Quick Delivery and Logistics Flexibility

Enjoy swift dispatching with prototype delivery in just 2-5 days and batch orders ready within 7-15 days. With export options from India and flexible FOB port choices, your transportation needs are efficiently managed. We maintain stock ready for key materials, ensuring orders are fulfilled promptly. Flexible payment terms cater to international clients, streamlining every step from production to shipment for a seamless procurement experience.

FAQ's of Pcb rapid prototype services gerber file schematic electronic circuit board pcb pcba design and software development Supplier:

Q: How can I submit Gerber files and schematics for PCB prototyping?

A: You can send Gerber, ODB++, Altium, Eagle, or OrCAD files directly via our secure upload portal or email them to our support team, ensuring all layers and BOM details are included for rapid processing.

Q: What is your standard lead time for PCB prototype orders?

A: For prototypes, our typical dispatching window is 2-5 days, while batch productions are completed within 7-15 days, depending on complexity and component sourcing requirements.

Q: What are the main benefits of your PCB rapid prototype services?

A: Our services offer a gorgeous range of board customizations, superior assembly capabilities (SMT, THT, mixed, BGA, QFN), comprehensive design and software development support, and reliable supply chain management-all tailored for diverse, high-demand applications.

Q: Where can your PCBs be applied?

A: Our PCBs are suitable for consumer electronics, automotive, medical devices, industrial control systems, IoT, and communications, offering high performance even in challenging environments.

Q: What testing processes do you implement for PCBs?

A: We employ flying probe, AOI (Automated Optical Inspection), and E-test procedures to ensure every PCB matches required specifications, with options for controlled impedance and rigorous electrical testing.

Q: How do you handle transportation and shipment for export orders?

A: All orders are vacuum-packed and shipped in ESD anti-static packaging. We offer flexible FOB ports from India and arrange transportation logistics based on your location and chosen delivery method.
