Product Details:

Voltage Endurance >500V
Hole Size 0.3 mm (min)
Min. Line Spacing 0.13 mm
Board Type Double sided, FR4 rigid
Impedance Controlled impedance supported
Flame Resistance Level UL94 V-0
Min. Line Width 0.15 mm
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

pcb printed circuit board assembly gh60 staggeredprinted mechanical keyboard pcb Price And Quantity

Price Or Price Range INR
Minimum Order Quantity 1

Mounting Holes Supports case and plate mounting
Stencil Support Yes
Connector Type USB-C / Mini-USB (dependent on assembly)
Compatible Layout GH60 Staggered (60% layout)
Operating Temperature Range -40C to +85C
Supported Key Switches MX-compatible (Cherry, Gateron, etc.)
Assembly Type SMT/DIP mixed assembly
Programming QMK/VIA firmware compatible
RoHS Compliance Yes

pcb printed circuit board assembly gh60 staggeredprinted mechanical keyboard pcb Product Specifications

Panel Size 10 cm x 30 cm (customizable)
Surface Finish HASL (Lead-Free)
Min. Line Width 0.15 mm
Insulation Resistance >10^12
Soldermask Green
Base Material FR4 Epoxy Glass
Copper Thickness 1 oz/ft2 (35m)
Board Thickness 1.6 mm
Color Green
Voltage Endurance >500V
Test 100% E-test
Number Of Layers 2 Layer
Hole Size 0.3 mm (min)
Min. Line Spacing 0.13 mm
Board Type Double sided, FR4 rigid
Product Type Mechanical Keyboard PCB Assembly
Electrical Components Diodes, Resistors, Stabilizer slots
Sensor Switch Mechanical key switch compatible
Impedance Controlled impedance supported
Flame Resistance Level UL94 V-0
Silkscreen White

Mounting Holes Supports case and plate mounting
Stencil Support Yes
Connector Type USB-C / Mini-USB (dependent on assembly)
Compatible Layout GH60 Staggered (60% layout)
Operating Temperature Range -40C to +85C
Supported Key Switches MX-compatible (Cherry, Gateron, etc.)
Assembly Type SMT/DIP mixed assembly
Programming QMK/VIA firmware compatible
RoHS Compliance Yes

Product Description

Experience a radiant typing upgrade with our new release GH60 Staggered Mechanical Keyboard PCB! This top-drawer PCB is currently in demand for keyboard enthusiasts seeking a polished and customizable solution. On sale now, it features a robust FR4 rigid double-sided board, 1.6 mm thickness, and supports MX-compatible switches. Seamlessly connect via USB-C or Mini-USB. Enjoy QMK/VIA firmware compatibility for easy programming. Engineered with RoHS compliance and a flame resistance rating of UL94 V-0, this PCB combines safety, reliability, and supreme performance for your unique builds.

Versatile Features & Broad Applications

The PCB Printed Circuit Board Assembly GH60 StaggeredPrinted Mechanical Keyboard PCB stands out with its support for case and plate mounting, white silkscreen, and custom panel sizes. Its robust build and compatibility with both SMT/DIP assembly techniques suit both hobbyists and commercial users. Ideal for office workstations, gaming setups, and professional input devices, the PCB's precise construction and high-quality electrical components ensure excellent performance on various application surfaces for demanding projects.

Domestic Market & Efficient Shipping

Serving the main domestic market across India, we ensure prompt service whether you're sampling or ordering in bulk. Sample units for evaluation are available upon request. Our FOB port is conveniently situated for efficient transportation, ensuring swift order processing. By utilizing both standard and express shipping options, buyers receive accurate delivery estimates with every order. Our streamlined logistics guarantee safe and timely arrival, supporting every step from inquiry to doorstep delivery.

FAQ's of pcb printed circuit board assembly gh60 staggeredprinted mechanical keyboard pcb:

Q: How do I program the PCB for custom key layouts?

A: The GH60 Staggered Mechanical Keyboard PCB is compatible with QMK and VIA firmware, allowing users to program and customize key layouts effortlessly using supported software interfaces.

Q: What connector options are available for this PCB?

A: Depending on your assembly, the PCB supports either USB-C or Mini-USB connectors, providing flexibility for various keyboard builds and personal preferences.

Q: Where can this PCB be used commercially?

A: This PCB is ideal for use in offices, gaming environments, and professional input device manufacturing, thanks to its robust build and versatile compatibility.

Q: What is the process for ordering samples?

A: To order a sample, contact our sales team. We provide sample units for evaluation, complete with delivery timelines and shipping estimates to facilitate your testing and decision-making process.

Q: What benefits do the mounting and electrical features provide?

A: The PCB supports both case and plate mounting, accepts a wide range of MX-compatible mechanical switches, and incorporates durable diodes, resistors, and stabilizer slots-ensuring top-drawer reliability and tailored performance.
