One stop Custom Mobile Phone Fast charging 3.0 18W USB Type C pd 20w charger pcba Board Manufacturer

One stop Custom Mobile Phone Fast charging 3.0 18W USB Type C pd 20w charger pcba Board Manufacturer

Get a Price/Quote

Product Details:

Silkscreen White
Test 100% E-Test, AOI
Soldermask Green
Board Type Rigid PCB
Min. Line Width 0.1mm
Insulation Resistance >10^12
Min. Line Spacing 0.1mm
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

One stop Custom Mobile Phone Fast charging 3.0 18W USB Type C pd 20w charger pcba Board Manufacturer Price And Quantity

Minimum Order Quantity 1 Piece

OEM/ODM Supported
Application Mobile phones, tablets, fast charging devices
Protection Features Over-current, Over-voltage, Short-circuit, Over-temperature protection
Operating Temperature -20C ~ +70C
Storage Temperature -40C ~ +85C
Efficiency >87%
Output Voltage/Current 5V/3A, 9V/2A, 12V/1.5A (18W QC 3.0); 20W USB Type-C PD
Charging Protocols Supported QC 3.0, USB PD 2.0/3.0
Input Voltage 100-240V AC, 50/60Hz

One stop Custom Mobile Phone Fast charging 3.0 18W USB Type C pd 20w charger pcba Board Manufacturer Product Specifications

Hole Size Min. 0.2mm
Voltage Endurance 1500V AC/min
Electrical Components Included (ICs, capacitors, resistors, etc.)
Flame Resistance Level UL94V-0
Sensor Switch Not included
Color Green
Impedance Controlled, on request
Board Type Rigid PCB
Min. Line Width 0.1mm
Soldermask Green
Base Material FR4
Product Type Custom Mobile Phone Fast Charging Charger PCBA Board
Min. Line Spacing 0.1mm
Test 100% E-Test, AOI
Number Of Layers 2 Layers
Silkscreen White
Surface Finish HASL, Lead-Free
Insulation Resistance >10^12
Board Thickness 1.6mm
Copper Thickness 1oz (35um)
Panel Size Customizable

OEM/ODM Supported
Application Mobile phones, tablets, fast charging devices
Protection Features Over-current, Over-voltage, Short-circuit, Over-temperature protection
Operating Temperature -20C ~ +70C
Storage Temperature -40C ~ +85C
Efficiency >87%
Output Voltage/Current 5V/3A, 9V/2A, 12V/1.5A (18W QC 3.0); 20W USB Type-C PD
Charging Protocols Supported QC 3.0, USB PD 2.0/3.0
Input Voltage 100-240V AC, 50/60Hz

Product Description

Experience opulent charging prowess with our one-stop custom Mobile Phone Fast Charging 3.0 18W USB Type-C PD 20W charger PCBA Board. Boasting top-tier electrical components, superb efficiency >87%, and full compliance with QC 3.0 & USB PD 2.0/3.0 protocols, this board is designed for high performance and utmost reliability. It's a bargain you cannot ignore-order today and get it now to empower your devices with rapid, safe charging. Ideal for OEM/ODM, customizable sizes, and strict protection for peace of mind. Seize superb value and uncompromising quality!

Superior Features & Plant Application Highlights

Our fast charging PCBA board is expertly engineered for mobile phones, tablets, and various fast charging devices. Manufactured in a state-of-the-art facility, it integrates advanced safety protections-over-current, over-voltage, short-circuit, and over-temperature-making it both robust and reliable. Features include dual charging protocols, customizable panel sizes, and a rigid 2-layer green PCB that ensures excellent insulation resistance and durability in diverse environments. Designed for OEM and ODM, it supports seamless integration in top charging products.

Global Export Markets & Secure Packaging Advantage

Our charger PCBA boards are exported to major international markets, ensuring global reach for our industry partners. Each unit is securely packaged for safe freight transit, maintaining quality on arrival. We prioritize low-cost, efficient delivery while providing the lowest price for all our clients. Every board is accompanied by essential certifications, ensuring compliance and safety. Choose us for packaging excellence, certified reliability, and prompt delivery, all at an unbeatable cost advantage.

FAQ's of One stop Custom Mobile Phone Fast charging 3.0 18W USB Type C pd 20w charger pcba Board Manufacturer:

Q: How do I benefit from using your fast charging PCBA board?

A: Our fast charging PCBA board offers rapid, safe charging, advanced protective features, and superb efficiency, guaranteeing both device safety and faster charging cycles for mobile devices and tablets.

Q: What charging protocols are supported by this board?

A: The board supports advanced protocols including QC 3.0 and USB PD 2.0/3.0, providing compatibility with a wide range of devices for swift, reliable charging performance.

Q: Where can the custom PCBA board be applied?

A: These PCBA boards are ideal for integration into mobile phone chargers, tablet chargers, and any device requiring fast charging capabilities, especially for OEM and ODM projects.

Q: What is the process for ordering customized boards?

A: You can specify panel size, protocol requirements, and other customization options when placing an order. Our manufacturing team will tailor the board features to fit your needs, ensuring top-tier performance.

Q: How is the product packaged for export and what certifications accompany it?

A: Every board is carefully packaged to prevent damage during transit, and exported with all necessary certifications, assuring international standards of safety, insulation, and environmental compliance.
