Product Details:

Test E-test, AOI, X-ray for BGA
Min. Line Width 0.075mm (3mil)
Soldermask Green, Blue, Red, Black, White, Custom
Flame Resistance Level UL94-V0
Insulation Resistance >10^12
Silkscreen White, Black, Yellow silkscreen available
Hole Size Min 0.2mm or as specified
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

OEM PCB Printed Circuit Board PCB design Assembly PCBA Prototyping Manuafcturing Shenzhen SMT DIP Custom PCB Fabrication Factory Price And Quantity

Minimum Order Quantity 1 Piece

OEM PCB Printed Circuit Board PCB design Assembly PCBA Prototyping Manuafcturing Shenzhen SMT DIP Custom PCB Fabrication Factory Product Specifications

Board Type Rigid, Flex, Rigid-Flex
Soldermask Green, Blue, Red, Black, White, Custom
Surface Finish HASL, ENIG, OSP, Silver, Gold, Lead-free HASL
Base Material FR-4, Aluminum, CEM-1, CEM-3, Rogers, Polyimide
Impedance Controlled impedance available as per design
Min. Line Spacing 0.075mm (3mil)
Voltage Endurance Up to 500V AC/DC (varies by design)
Copper Thickness 1 oz to 3 oz
Electrical Components SMT, DIP, SMD, Through hole
Number Of Layers 1-32 layers
Hole Size Min 0.2mm or as specified
Panel Size Custom / As per customer design
Color Green, Blue, Black, Red, Yellow or as requested
Sensor Switch N/A (customizable as per product design)
Board Thickness 0.4mm to 3.2mm
Silkscreen White, Black, Yellow silkscreen available
Min. Line Width 0.075mm (3mil)
Product Type OEM PCB Printed Circuit Board
Insulation Resistance >10^12
Test E-test, AOI, X-ray for BGA
Flame Resistance Level UL94-V0

Min Trace/Space 3mil/3mil (0.075mm/0.075mm)
Copper Weight Tolerance 0.25oz
Special Technology Capability HDI, Microvias, Gold Finger, Edge Plating, Carbon Ink
Blind/Buried Vias Supported
Design Software Supported Altium Designer, Eagle, Protel, OrCAD, KiCAD, etc.
Finished Board Weight Depends on size/layer/material (custom per order)
Assembly Type Single or Double Side SMT Placement
MOQ No MOQ requirement for prototypes
RoHS Compliance RoHS compatible production available
Lead Time Prototype 3-7 days, Mass production 7-15 days
Operating Temperature -40C to 130C (depends on material)
Component Procurement Full turnkey, Partial turnkey or Consigned
Thickness Tolerance 10% or as specified
Packaging Vacuum packing, ESD safe packing, custom packaging available
Assembly Service SMT (Surface Mount Technology), DIP (Dual Inline Package), Mixed Technology
Max Finished Board Size Up to 600mm x 1200mm
Prototyping Capability Quick turn prototypes available (24-72 hours)
PCBA Testing ICT, FCT, Burn-in, Functional Test, In-circuit Test

Product Description

Explore new horizons in electronics with our OEM PCB Printed Circuit Board design and assembly solutions. Grab the opportunity to experience unparalleled manufacturing excellence from Shenzhen, merging SMT, DIP, and mixed technology for inestimable value. Every order, from rapid prototyping to full-scale production, is handled with meritorious attention to detail. Choose from custom board sizes, colors, and technologies like HDI or gold fingers, supported by RoHS-compliant processes. We offer turnkey component procurement and rigorous testing, ensuring unparalleled reliability for all your PCB needs, without MOQ restrictions.

Versatile Usage and Application Guidance

Our OEM PCB Printed Circuit Board assemblies are expertly crafted for diverse applications, including industrial equipment, consumer electronics, medical devices, and automotive systems. Suitable for rapid prototyping or end-product integration, these PCBs can be used as control modules, power management boards, or sensor interfaces. Direction of use is straightforward-simply integrate them into your circuit design according to your project's technical requirements for unmatched performance and reliability across multiple sectors.

FOB Port, Fast Delivery, and Samples-Your Proposal Estimated Fast

Benefit from our strategic Shenzhen FOB port for efficient export and prompt shipments worldwide. Our streamlined process ensures proposal amount clarity and quick dispatch-prototypes are ready within 3-7 days, mass production from 7-15 days. Sample options are available to help you estimate fit for purpose before full orders. Trust us for reliable, timely deliveries and dedicated support tailored to your custom PCB manufacturing needs.
