Electronic assembly Led aluminum PCB&pcbaBoard Smd 3535 5730 3w 5w 7w 9w 12w 15w 18w 94v-0 1000 lumen led circuit board Supplier

Electronic assembly Led aluminum PCB&pcbaBoard Smd 3535 5730 3w 5w 7w 9w 12w 15w 18w 94v-0 1000 lumen led circuit board Supplier

Get a Price/Quote

Product Details:

Silkscreen White / Black / Yellow
Flame Resistance Level UL 94V-0
Impedance Customizable
Board Type LED Aluminum PCB
Soldermask White / Black / Customized
Hole Size 0.25mm - 6.0mm
Min. Line Spacing 0.1mm
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Electronic assembly Led aluminum PCB&pcbaBoard Smd 3535 5730 3w 5w 7w 9w 12w 15w 18w 94v-0 1000 lumen led circuit board Supplier Price And Quantity

Price Or Price Range INR
Minimum Order Quantity 1

RoHS Compliance Yes
Power Ratings 3W, 5W, 7W, 9W, 12W, 15W, 18W
LED Type SMD 3535 / SMD 5730
Working Life >30,000 hours
Application LED Lighting, Downlight, Streetlight, Industrial Lighting
Operating Temperature -40C to +85C
Luminous Flux Up to 1000 lumens
Assembly Type Surface Mount (SMT/SMC)

Electronic assembly Led aluminum PCB&pcbaBoard Smd 3535 5730 3w 5w 7w 9w 12w 15w 18w 94v-0 1000 lumen led circuit board Supplier Product Specifications

Flame Resistance Level UL 94V-0
Product Type Electronic assembly LED aluminum PCB & PCBA Board
Color White or customized
Board Type LED Aluminum PCB
Impedance Customizable
Electrical Components SMD 3535, SMD 5730 LEDs and electronic drivers
Copper Thickness 1oz - 2oz
Soldermask White / Black / Customized
Insulation Resistance > 10^12
Hole Size 0.25mm - 6.0mm
Panel Size Customizable
Board Thickness 1.0mm - 1.6mm
Number Of Layers Single/Double Layer
Surface Finish HASL, ENIG, OSP, Lead-free HASL
Sensor Switch Not included (customizable upon request)
Base Material Aluminum
Min. Line Spacing 0.1mm
Test 100% E-test
Voltage Endurance AC 220V / DC 12V or as specified
Silkscreen White / Black / Yellow
Min. Line Width 0.1mm

RoHS Compliance Yes
Power Ratings 3W, 5W, 7W, 9W, 12W, 15W, 18W
LED Type SMD 3535 / SMD 5730
Working Life >30,000 hours
Application LED Lighting, Downlight, Streetlight, Industrial Lighting
Operating Temperature -40C to +85C
Luminous Flux Up to 1000 lumens
Assembly Type Surface Mount (SMT/SMC)

Product Description

Jump on our invincible Electronic Assembly LED Aluminum PCB & PCBA Boards, designed for pristine performance. With competitive pricing, these gorgeous boards support SMD 3535 and SMD 5730 LED types across a power spectrum from 3W to 18W. Delivering up to 1000 luminous lumens, they're perfect for advanced lighting assemblies-be it industrial, streetlight, or downlight applications. Featuring high-grade aluminum and RoHS compliance, they withstand extreme temperatures (-40C to +85C), ensuring durable, long-lasting operation. Secure your purchase from a trusted Indian supplier and illuminate your projects with reliability.

Superior Material Feature and Versatile Applications

Our LED aluminum PCB & PCBA boards are crafted with premium-grade aluminum, ensuring excellent thermal conductivity and structural stability. Their SMT-optimized design allows for seamless assembly, making them ideal for commercial lighting, downlights, streetlights, and industrial applications. The high luminous output and customizable options support both small-scale and large-scale projects. Choose these boards for their robust construction, superior heat resistance, and flawless light diffusion across a broad range of lighting scenarios.

Domestic Reach, Export Potential, and Stock Availability

With stock ready for immediate Purchase Order fulfillment, our LED PCB & PCBA boards serve not just the domestic Indian market but also cater to a thriving export market. Each order is carefully packaged to ensure pristine delivery, meeting international safety standards. Certified with UL 94V-0 flame resistance and full RoHS compliance, our products guarantee quality. Jump on the opportunity to partner with a manufacturer-supplier who prioritizes timely shipments, stringent testing, and global customer satisfaction.

FAQ's of Electronic assembly Led aluminum PCB&pcbaBoard Smd 3535 5730 3w 5w 7w 9w 12w 15w 18w 94v-0 1000 lumen led circuit board Supplier:

Q: How do I purchase the Electronic Assembly LED Aluminum PCB & PCBA boards?

A: To make a purchase, simply contact us with your requirements, including power ratings, board size, and quantity. We offer competitive pricing and quick order processing for both domestic and export markets.

Q: What makes these LED PCBs invincible in industrial and commercial lighting?

A: Our LED PCBs are crafted from high-grade aluminum, ensuring outstanding thermal performance, flame resistance, and durability. Their robust design and superior lifespan (>30,000 hours) make them the ideal choice for demanding lighting environments.

Q: Where can these LED aluminum PCBs be used?

A: These PCBs are suitable for a broad range of applications, including LED lighting, downlights, streetlights, and industrial lighting. Their adaptability and high luminous output make them ideal for both indoor and outdoor settings.

Q: What material features enhance LED PCB performance and safety?

A: Key features include pristine aluminum substrates, superior copper thickness, high insulation resistance, and UL 94V-0 flame resistance, ensuring safe, efficient, and long-lasting illumination.

Q: How is product quality ensured for every purchase?

A: Every board undergoes 100% E-testing, is RoHS compliant, and certified to UL safety standards. Products are also securely packaged, ensuring they arrive in pristine condition with all specifications met.
