Product Details:

Impedance Controlled impedance 10%
Min. Line Width 0.075mm
Test 100% E-Test, AOI, Flying Probe
Flame Resistance Level UL94 V-0
Silkscreen White, Yellow, Black
Hole Size Min 0.15mm
Min. Line Spacing 0.075mm
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Custom electronics printed pcb circuit boards hdi double-sided multilayer pcb pcba gerber service assembly manufacturer Price And Quantity

Price Or Price Range INR
Minimum Order Quantity 1

Packing Vacuum packed with ESD protection
Component Sourcing Complete BOM support and sourcing
Gerber File Service Supported (format: RS-274X)
Sample Lead Time 5-7 working days for prototype
Assembly Type SMT, Through Hole, Mixed
Mass Production Lead Time 10-18 working days (depends on complexity)
Application Consumer electronics, automotive, industrial, medical devices, telecom
Maximum Board Size Up to 500mm x 600mm
Service Provided PCB Fabrication & Turnkey PCBA Assembly
Connector Type Custom as per design (Headers, Sockets, etc.)
OEM/ODM Service Available
Board Shape Custom shapes supported (Round, Irregular, etc.)

Custom electronics printed pcb circuit boards hdi double-sided multilayer pcb pcba gerber service assembly manufacturer Product Specifications

Sensor Switch Available as customized component in assembly
Hole Size Min 0.15mm
Product Type Custom Electronics Printed PCB Circuit Boards
Silkscreen White, Yellow, Black
Soldermask Green, Red, Black, Blue, Matte and Gloss finish
Board Type Double-Sided, Multilayer, HDI PCB
Flame Resistance Level UL94 V-0
Voltage Endurance 2000V (Typical)
Insulation Resistance >10^12
Surface Finish HASL, ENIG, OSP, Immersion Silver/Tin, Gold Plating
Board Thickness 1.6mm standard (customizable 0.2~3.2mm)
Test 100% E-Test, AOI, Flying Probe
Min. Line Width 0.075mm
Copper Thickness 1oz, 2oz (customizable)
Electrical Components SMT & DIP as per BOM
Panel Size Customized as per requirements
Min. Line Spacing 0.075mm
Impedance Controlled impedance 10%
Base Material FR-4, Rogers, High TG, Aluminum, CEM-1/CEM-3
Number Of Layers 2-20 Layers (HDI and Multilayer available)
Color Green, Blue, Black, Red, Yellow, White (Silkscreen options)

Packing Vacuum packed with ESD protection
Component Sourcing Complete BOM support and sourcing
Gerber File Service Supported (format: RS-274X)
Sample Lead Time 5-7 working days for prototype
Assembly Type SMT, Through Hole, Mixed
Mass Production Lead Time 10-18 working days (depends on complexity)
Application Consumer electronics, automotive, industrial, medical devices, telecom
Maximum Board Size Up to 500mm x 600mm
Service Provided PCB Fabrication & Turnkey PCBA Assembly
Connector Type Custom as per design (Headers, Sockets, etc.)
OEM/ODM Service Available
Board Shape Custom shapes supported (Round, Irregular, etc.)

Product Description

Experience elite engineering with our matchless Custom Electronics Printed PCB Circuit Boards. As a paragon manufacturer and exporter, we offer top-tier HDI, double-sided, and multilayer PCB and turnkey PCBA assembly services. In-demand for consumer electronics, automotive, industrial, medical, and telecom sectors, our clearance-grade solutions support custom shapes, connectors, controlled impedance, and advanced finishes. Enjoy rapid sample lead times (5-7 days), comprehensive BOM sourcing, and 100% testing including E-test and AOI. Choose from a range of board sizes, colors, and material options. OEM/ODM, Gerber file RS-274X, and worldwide export supported from India.
