Aluminum LED pcb circuit board one stop custom pcba board assembly manufacturing RGB pcb Supplier

Aluminum LED pcb circuit board one stop custom pcba board assembly manufacturing RGB pcb Supplier

Get a Price/Quote

Product Details:

Test E-Test, AOI
Hole Size Min 0.2 mm
Min. Line Spacing 0.1 mm
Flame Resistance Level UL94V-0
Min. Line Width 0.1 mm
Voltage Endurance Up to 3000V
Board Type Single sided/Double sided/Multilayer
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Aluminum LED pcb circuit board one stop custom pcba board assembly manufacturing RGB pcb Supplier Price And Quantity

Price Or Price Range INR
Minimum Order Quantity 1 Piece

Aluminum LED pcb circuit board one stop custom pcba board assembly manufacturing RGB pcb Supplier Product Specifications

Silkscreen White/Black
Test E-Test, AOI
Board Thickness 1.6 mm
Hole Size Min 0.2 mm
Soldermask White/Black/Custom
Base Material Aluminum (Metal Core PCB)
Product Type Aluminum LED PCB Circuit Board
Copper Thickness 1 oz (35m)
Board Type Single sided/Double sided/Multilayer
Insulation Resistance 10^12
Min. Line Spacing 0.1 mm
Electrical Components Custom Assembly (SMD, DIP, Mixed)
Color White
Flame Resistance Level UL94V-0
Number Of Layers 1/2/4 layers configurable
Voltage Endurance Up to 3000V
Min. Line Width 0.1 mm
Panel Size Customizable
Sensor Switch Optional
Surface Finish HASL, ENIG, OSP, Lead-free HASL
Impedance 10% Customized

Maximum Current Up to 10A supported
Assembly Service One-Stop (Turnkey) PCBA including SMT and Through Hole
Operating Temperature Range -40C to +130C
LED Type Compatibility RGB, SMD LEDs, High Power LEDs
Stencil Supply Available on request
OEM/ODM Capability Supported
Packing Anti-static bag & customized packaging
Application LED lighting, industrial, automotive, signage
Component Sourcing Full/Partial/BOM support
Connection Type Through-hole & SMD
Engineering Support DFM, DFA, protype to mass production

Product Description

Discover a trending and prime solution with our Aluminum LED PCB circuit board-your one-stop custom PCBA board assembly manufacturing partner. As a reputed exporter, manufacturer, and supplier in India, we deliver superb RGB PCB boards featuring both SMT and through-hole assembly. Experience valuable engineering support, component procurement options, and exceptional value in full turnkey service. From DFM to mass production, benefit from 1-4 layer customizable, high-power, durable boards tested for AOI and E-Test, supporting operating ranges of -40C to +130C. Procure a truly valuable board for your LED, signage, industrial, or automotive applications.

Versatile Applications & Commercial Benefits

Used for advanced LED lighting, signage, industrial, and automotive systems, our Aluminum LED PCB circuit boards serve as the backbone in RGB display, SMD, and high-power applications. Leveraging fine copper thickness with superb electrical performance, these boards are popularly used as valuable components in commercial, industrial, and OEM/ODM solutions, enhancing market value and operational efficiency across multiple domains.

Export, Certifications & Packaging Highlights

Dispatched globally from prime FOB ports in India, our trending Aluminum LED PCB circuit boards uphold international certifications such as UL94V-0 for flame resistance. All products are securely packaged in anti-static bags and available with custom packaging options, ensuring protection and sustained market value during transport. The list price is tailored for competitive markets, supporting high-volume commercial and industrial requirements.

FAQ's of Aluminum LED pcb circuit board one stop custom pcba board assembly manufacturing RGB pcb Supplier:

Q: How does your one-stop (turnkey) PCBA process work?

A: Our process encompasses complete PCBA services, from engineering design (DFM/DFA) and prototype to mass production. We support full or partial component procurement based on your BOM, provide assembly for SMD, DIP, or mixed types, and conduct rigorous E-Test and AOI before dispatch.

Q: What types of LED compatibility and applications does your PCB offer?

A: Our boards support RGB, SMD, and high-power LEDs, making them suitable for use in LED lighting, signage, automotive, and industrial sectors. Their robust design with customizable layers up to 4, superior current support (up to 10A), and wide thermal range ensure valuable performance in diverse applications.

Q: When can I request stencil supply or customized panel sizing?

A: Stencil supply is available upon request at any stage of your order. Panel sizes, soldermask, silkscreen colors, and board configurations are fully customizable during the quotation and design process to match your specific project or commercial requirements.

Q: Where are your Aluminum LED PCB circuit boards dispatched from?

A: Our manufacturing facilities and primary FOB ports are located in India, facilitating both domestic and international export to maximize your supply chain value.

Q: What certifications and tests ensure the quality of your PCB boards?

A: Each PCB is manufactured under rigorous standards and certified with UL94V-0 for flame resistance. E-Test and Automated Optical Inspection (AOI) further guarantee prime quality, supported by various surface finishes including HASL and ENIG, ensuring long-term reliability.

Q: How does your engineering support add value to the procurement process?

A: We provide valuable DFM/DFA support, technical consulting, and assistance from design to prototype and mass production, optimizing layouts for improved manufacturability and cost-efficiency while ensuring all boards meet your unique specifications.
