Advanced Small Size Radar Sensor PCBA manufacturer for Distance Measurement in Open Channels

Advanced Small Size Radar Sensor PCBA manufacturer for Distance Measurement in Open Channels

Get a Price/Quote

Product Details:

Min. Line Spacing 0.1 mm
Board Type Rigid FR4 PCB
Voltage Endurance 2,000V (min.)
Test Flying Probe, AOI
Silkscreen White
Insulation Resistance >10^12
Hole Size 0.2 mm min.
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Advanced Small Size Radar Sensor PCBA manufacturer for Distance Measurement in Open Channels Price And Quantity

Price Or Price Range INR
Minimum Order Quantity 1 Piece

Power Consumption <1W
Antenna Type Integrated Patch Antenna
Waterproof Level IP67 (with housing)
PCB Finish Smooth, Acid/Alkali resistant
Communication Interface UART/RS485/4-20mA Output
Measurement Accuracy 2 mm
Application Liquid Level, Flow Distance Measurement, Industrial Control
Operating Voltage DC 5V to 24V
Distance Measurement Range 0.2m - 20m (in open channels)
Response Time 100 ms
Weight Approx. 25g (PCB only)
Radar Operating Frequency 24 GHz
Firmware Customizable, Upgradeable via serial interface
Mounting Through-hole/Panel mount compatible
Operating Temperature -40C to +85C
Compliance CE, RoHS

Advanced Small Size Radar Sensor PCBA manufacturer for Distance Measurement in Open Channels Product Specifications

Voltage Endurance 2,000V (min.)
Number Of Layers 2
Min. Line Width 0.1 mm
Surface Finish HASL/ENIG
Impedance Controlled, 50
Board Thickness 1.6 mm
Soldermask Green, RoHS compliant
Silkscreen White
Test Flying Probe, AOI
Flame Resistance Level UL94 V-0
Product Type Radar Sensor PCBA for Distance Measurement
Insulation Resistance >10^12
Base Material FR4, High TG
Electrical Components SMD, Mixed Technology
Board Type Rigid FR4 PCB
Min. Line Spacing 0.1 mm
Hole Size 0.2 mm min.
Sensor Switch Integrated Radar-based Proximity Switch
Color Green
Copper Thickness 1 oz
Panel Size Custom (typically 100mm x 60mm)

Power Consumption <1W
Antenna Type Integrated Patch Antenna
Waterproof Level IP67 (with housing)
PCB Finish Smooth, Acid/Alkali resistant
Communication Interface UART/RS485/4-20mA Output
Measurement Accuracy 2 mm
Application Liquid Level, Flow Distance Measurement, Industrial Control
Operating Voltage DC 5V to 24V
Distance Measurement Range 0.2m - 20m (in open channels)
Response Time 100 ms
Weight Approx. 25g (PCB only)
Radar Operating Frequency 24 GHz
Firmware Customizable, Upgradeable via serial interface
Mounting Through-hole/Panel mount compatible
Operating Temperature -40C to +85C
Compliance CE, RoHS

Product Description

Reserve your place at the forefront of industrial measurement with this top-tier Advanced Small Size Radar Sensor PCBA, an unassailable leader for open channel distance measurement. Operating at a brilliant 24 GHz, it delivers eminent precision-2 mm accuracy-across a vast 0.2 to 20m range. Engineered in India by an in-demand exporter, this robust sensor boasts CE/RoHS compliance, IP67 waterproofing, and unrivaled versatility with UART/RS485/4-20mA outputs. Customizable, energy-efficient, and firmware-upgradeable, it is distinguished by its acid/alkali-resistant finish, high TG material, and flame resistance UL94 V-0, ensuring peak performance in the most challenging environments.

Competitive Edge, Broad Application Reach

Our advanced radar sensor PCBA is renowned for its eminent competitive advantages: exceptional measurement accuracy, unassailable build quality, and customizable firmware. The sensor is perfectly suited for monitoring liquid levels and flow measurement in open channels. It is tailored for industries where reliability is paramount, such as water management, industrial automation, and environmental control. The high IP67 waterproof rating ensures durability, while acid/alkali resistance extends operational lifespan even in harsh chemical or outdoor environments.

Markets, Pricing, and Efficient Logistics

Our radar sensor PCBA is highly sought after in both the domestic market and major international export destinations, including Europe, the Middle East, and Southeast Asia. We operate from a leading Indian FOB port, ensuring seamless logistics and timely delivery. Samples are available upon request to provide hands-on experience before full purchase. Competitive list prices and efficient shipping partnerships distinguish our company, ensuring unassailable product availability and rapid response to domestic and global customer demand.

FAQ's of Advanced Small Size Radar Sensor PCBA manufacturer for Distance Measurement in Open Channels:

Q: How does the Advanced Small Size Radar Sensor PCBA measure distance in open channels?

A: The radar sensor emits 24 GHz electromagnetic waves, which reflect off the liquid surface in open channels. By analyzing the time it takes for these waves to return, the sensor accurately calculates the distance with a precision of up to 2 mm.

Q: What are the key benefits of using this radar sensor PCBA in industrial applications?

A: This sensor offers unassailable accuracy, low power consumption (<1W), rapid response time (100 ms), and durability (IP67 waterproof, acid/alkali resistance). Its customizable firmware and multiple communication interfaces make it highly adaptable to diverse industrial needs.

Q: Where can this radar sensor PCBA be installed for optimal performance?

A: Ideal installation sites include water management systems, industrial control panels, open channels, and any location requiring precise liquid level or flow measurement. Its through-hole or panel mount compatibility and robust waterproof design allow versatile placement.

Q: What is the process for upgrading the sensor's firmware?

A: Firmware upgrades are easily performed via the serial communication interface, allowing users to keep the device updated and integrate custom features to meet evolving industry requirements.

Q: When should samples of the radar sensor PCBA be requested and how are they shipped?

A: Samples can be requested before finalizing bulk orders, providing customers an opportunity for evaluation. They are shipped securely from our Indian FOB port, with reliable logistics partners ensuring prompt and safe delivery to both domestic and export markets.
